W10 DC TOP - Two‑person helm console, foldable console top and roof with quick‑release fastening.
ALUCAT® W10 DC TOP is designed for professionals who require reliable weather protection without sacrificing logistical flexibility. The dual‑operator control console is equipped with a robust roof that shelters the crew from rain and direct sun. An innovative folding mechanism allows the roof and upper section of the console to be lowered, a critical feature during transport, storage, or when passing under very low bridges.
Technical specifications:
Foldable roof: Provides reliable protection while enabling low‑profile transport when required.
NATO‑registered: The W10 series delivers proven quality and safety for authority use.
Deck space: 10 m² of fully unobstructed and reconfigurable space for professional equipment.
Stability: The catamaran hull ensures the vessel remains level even when the crew is moving or when loads are being handled.
| Boat type | Catamaran |
| Material | Marine aluminum 5083 |
| Usable area on flat deck | 10 m² |
| Hull length | 5,95 m |
| Overall width | 2,35 m |
| (Bow ramp width) | 0,75 – 0,9 m |
| Hull weight | ~ 1000 kg |
| Load capacity | ~ 800 kg |
| Draft | ~ 0,30 m |
| Number of persons | 6 |
| Tank size | 147 l |
| Engine height | L |
| Recommended power | 1 x 100 – 180 hp 2 x 60 – 90 hp |
| Approvals (certifications) | CE / C Professional boat approval (DIN 14961, EN 1914) (NMMA) |
